Hydraulic hammers The range of hammers available at ITR is from 70 kg to 10 tons, so a suitable hammer can always be found.

Pulveriser The innovative PRV (Pressure Relief Valve) protects the crusher against peaks of extremely high pressure, which increases the service life and makes working safer.

Pulverisers Equipped with the PRV (Pressure Relief Valve) as standard, which protects the scissors against high pressure.

Scrap shears The body of Hardox eng Strenx makes the scrap shears of ITR Benelux durable and reliable.

ABOUT OUR ATTACHMENTS

ITR demolition equipment was created to offer a total solution. The product line is completely designed, manufactured and assembled in Italy. The use of these products makes it possible to demolish concrete, steel, brick and wood structures, to cut the demolished material and to separate the reinforcing steel from the concrete to facilitate its transport and recycling.

The equipment is made of STRNX steel - highly elastic and resilient to absorb the stress generated by the hydraulic cylinder - and HARDOX steel, highly wear-resistant and able to protect all the parts in direct contact with the material being demolished.
The innovative PRV (Pressure Relief Valve) system protects the equipment from high pressure peaks by draining the excess oil directly into the tank.

Technical information

Crushers
Pulverisers
Shears

Technical Data	UNC115	UNC140	UNC190	UNC220	UNC275	UNC380	UNC480	UNC580	UNC790	UNC1195
Opening (A)	600 mm	710 mm	825 mm	920 mm	1100 mm	1350 mm	1500 mm	1650 mm	1830 mm	2300 mm
Length (B)	1700 mm	2010 mm	2180 mm	2300 mm	2700 mm	2800 mm	2850 mm	3000 mm	3200 mm	3820 mm
Width (C)	460 mm	480 mm	665 mm	740 mm	880 mm	1034 mm	1055 mm	1080 mm	1185 mm	1410 mm
Excavator Weight	12/16 ton	16/22 ton	22/30 ton	30/40 ton	35/50 ton	36/49 ton	50/65 ton	60/80 ton	80/100 ton	90/150 ton
Equipment Weight	1150 Kg	1400 Kg	1900 Kg	2200 Kg	2750 Kg	3800 Kg	4800 Kg	5800 Kg	7900 Kg	11950 Kg
Max Pressure	300 bar	310 bar	320 bar	320 bar	320 bar	340 bar	340 bar	340 bar	340 bar	340 bar
Oil Max Capacity (L/min)	200/220	220/240	240/280	300/320	300/340	300/380	350/400	380/450	400/500	450/700
Rotation Oil Pressure	60 bar	60 bar	60 bar	60 bar	60 bar	60 bar	100 bar	100 bar	100 bar	100 bar
Rotation Oil Capacity (L/min)	30	30	30	30	40	40	60	60	60	70

Technical Data	UNP60	UNP105	UNP161	UNP190	UNP258	UNP304	UNP394	UNP600	UNP780	UNP995
Opening (A)	520 mm	630 mm	780 mm	820 mm	910 mm	1040 mm	1130 mm	1280 mm	1350 mm	1720 mm
Length (B)	1410 mm	1900 mm	2330 mm	2390 mm	2510 mm	2660 mm	2850 mm	3230 mm	3400 mm	3800 mm
Width (C)	340 mm	380 mm	460 mm	480 mm	480 mm	510 mm	550 mm	660 mm	620 mm	650 mm
Excavator Weight	7/12 ton	9/15 ton	15/20 ton	18/26 ton	24/32 ton	30/40 ton	38/55 ton	50/80 ton	70/90 ton	90/120 ton
Equipment Weight	600 Kg	1050 Kg	1610 Kg	1900 Kg	2580 Kg	3040 Kg	3940 Kg	6000 Kg	7800 Kg	9950 Kg
Max Pressure	250 bar	310 bar	320 bar	320 bar	320 bar	320 bar	320 bar	320 bar	330 bar	340 bar
Oil Max Capacity (L/min)	80/100	180/220	180/220	200/240	250/300	300/350	300/350	300/350	400/500	500/600
Rotation Oil Pressure	60 bar	60 bar	60 bar	60 bar	60 bar	60 bar	60 bar	100 bar	100 bar	100 bar
Rotation Oil Capacity (L/min)	10	30	30	30	30	30	30	60	60	60

Technical Data	UNS64	UNS125	UNS203	UNS253	UNS320	UNS391	UNS563	UNS690	UNS780	UNS995	UNS1150
Opening (A)	365 mm	440 mm	470 mm	550 mm	590 mm	680 mm	800 mm	850 mm	880 mm	920 mm	950 mm
Length (B)	1880 mm	2450 mm	3040 mm	3060 mm	3520 mm	3660 mm	4100 mm	4700 mm	4800 mm	5000 mm	5300 mm
Width (C)	240 mm	400 mm	500 mm	510 mm	590 mm	600 mm	690 mm	800 mm	830 mm	900 mm	950 mm
Excavator Weight at bucket place	7/12 ton	12/18 ton	20/28 ton	26/34 ton	34/40 ton	40/50 ton	50/70 ton	70/100 ton	80/110 ton	90/120 ton	100/130 ton
Excavator Weight at boom place	4/7 ton	7/10 ton	14/18 ton	16/22 ton	22/30 ton	26/35 ton	30/45 ton	45/60 ton	50/70 ton	70/90 ton	90/110 ton
Equipment Weight	640 Kg	1250 Kg	2030 Kg	2530 Kg	3200 Kg	3910 Kg	5630 Kg	6900 Kg	7800 Kg	9950 Kg	11500 Kg
Max Pressure	250 bar	310 bar	340 bar	340 bar	340 bar	340 bar	340 bar	340 bar	340 bar	340 bar	340 bar
Oil Max Capacity (L/min)	80/100	150/220	200/220	200/240	240/300	300/350	350/450	350/400	400/500	500/800	700/900
Rotation Oil Pressure	60 bar	140 bar	140 bar	140 bar	140 bar	140 bar	140 bar	140 bar	140 bar	140 bar	140 bar
Rotation Oil Capacity (L/min)	20	30	30	30	30	30	60	60	60	60	60
Hydraulic Rotation	360	360	360	360	360	360	360	360	360	360	360
